Microcomputer Solar Geyser System Controller TK-8A

Microcomputer Solar Geyser System Controller TK-8A with temperature measurement and the water level in the tank to control the pump, heater, etc. Recommended for solar systems

 Functions:

– Water level indicator: 5 levels

 Technical data:

– Dimensions: 200mm x 128mm x 40mm

– Powers supply ~ 220V (AC)

– Power consumption: < 6W

– Temperature measurement range: 0 ~ 99°C

– Temperature measurement accuracy: ± 2°C

– Maximum power of the connected electric heater: <1500 W

– Maximum power of connected pump or electric heating cables: <500 W

– Creepage: <10mA/0.1 S

– Solenoid valve power supply: = 12V (DC)

– Solenoid valve operating pressure range: 0.02 MPa – 0.8 MPa

– Water level sensor with NTC 10K temperature sensor, temperature measurement: <135°C, cable resistant to a temperature of <105 ° C, cable length: 20, 24 or 30 m
